Nexus AI Server
1 / 5
| CPU | Supports 2 x 5th/4th Gen Intel® Xeon® Scalable processors, TDP 350W |
| GPU | Supports up to 8/10 x dual-width GPUs |
| Memory | Supports 32 x DDR5 DIMMs, up to 5600MHz; Supports RDIMM, 3DS RDIMM, and up to 8TB of memory |
| Storage Controller | Integrated 6Gb/s onboard SATA, optional support for 12Gb/s SAS HBA and 12Gb/s SAS RAID card; Supports VMD and VROC |
| PCIe Extension | Supports up to 12 x PCIe standard slots; Supports 8 x GPUs + 1 x PCIe 5.0 x16 + 2 x PCIe 5.0 x8; Supports 8 x GPUs + 4 x PCIe 5.0 x8; Optional support for 1 x built-in RAID or SAS HBA standard card (PCIe 4.0x8) |
| Local Storage | Supports 12 x 3.5"/2.5" hard drives, optional 8 x 3.5"/2.5" hard drives; Supports up to 4 x U.2 NVMe SSDs; Supports 2 x M.2 (SATA 3.0/PCIe 4.0 x4, 2280&22110) |
| Network | 1 x 1Gb RJ45 dedicated management network port; Supports 1 x OCP3.0 network card, optional PCIe 5.0 x8 or x16; Optional 4x1GbE / 2x10Gb SFP+ / 4x10Gb SFP+ / 2x25Gb SFP28 |
| I/O Ports | Front: 2 x USB 3.0, 1 x VGA; Rear: 1 x serial port, 2 x USB 3.0, 1 x VGA, 1 x RJ45 management port |
| Fan | 8 x 8056 high-speed fans, hot swappable, N+1 redundant; Supports optional configuration of rear fan module |
| Power Supply | 4 x CRPS power modules, hot swapping, 2+2/3+1/1+1 redundant mode; Optional 1600W/2000W/2400W/2700W Platinum grade |
| Management | Integrated BMC management chip AST2600, supporting IPMI2.0, Redfish, SOL, KVM, virtual media, etc. |
| Safety Functions | Optional TPM/TCM security module, intrusion detection, locking upper cover (tool-free); BIOS/BMC dual flash redundant design |
| Chassis Size | 4U standard rackmount; 3.5" HDD: 448mm(W) x 175mm(H) x 822mm(D); 2.5" HDD: 448mm(W) x 175mm(H) x 772mm(D) |
| Temperature | Operating: 5ºC - 35ºC; Storage: -40ºC - 65ºC |
| OS Support | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, and Debian |
