Buy Stock DE2000H OEM Server Internet Computer Server Price
| Form factor |
- DE2000H 2U24 SFF controller enclosure (Machine Type 7Y71): 2U rack mount.
- DE2000H 2U12 LFF controller enclosure (Machine Type 7Y70): 2U rack mount.
- DE240S 2U24 SFF expansion enclosure (Machine Type 7Y68): 2U rack mount.
- DE120S 2U12 LFF expansion enclosure (Machine Type 7Y63): 2U rack mount.
|
| Controller configuration |
Dual active-active controller configuration with automatic load balancing. |
| RAID levels |
RAID 0, 1, 3, 5, 6, and 10; Dynamic Disk Pools. Note: RAID 3 can be configured only through the CLI. |
| Controller system memory |
16 GB per system (8 GB per controller). Cache mirroring between the controllers. Flash-backed cache protection (includes battery for destaging to flash). |
| Expansion enclosure support |
- DE2000H 2U24 SFF controller: 3x DE120S or 3x DE240S
- DE2000H 2U12 LFF controller: 3x DE120S or 3x DE240S
- Expansion enclosures may be mixed up to a maximum of 3 expansion enclosures
|
| Drive bays |
Up to 4 enclosures per system (Controller unit with up to 3 expansion units):
- Up to 48 LFF hot-swap drive bays (Up to 4x 2U12 LFF enclosures)
- Up to 96 SFF hot-swap drive bays (Up to 4x 2U24 SFF enclosures)
- Intermix of 2U24 SFF and 2U12 LFF enclosures is supported.
|
| Drives |
2U24 SFF drives:
- 10K rpm SAS HDDs
- 10K rpm SAS FIPS HDDs
- SAS SSDs (1 DWD)
- SAS SSDs (3 DWD)
- SAS FIPS SSDs (3 DWD)
2U12 LFF drives:
- 7.2K rpm NL SAS HDDs
- 7.2K rpm NL SAS FIPS HDDs
- SAS SSDs (3 DWD)
- SAS FIPS SSDs (3 DWD)
|
| Storage capacity |
- All SFF drives: Up to 1.47 PB (96x 15.36 TB SFF SSDs)
- All LFF drives: Up to 864 TB (48x 18TB LFF HDDs)
|
| Host operating systems |
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere |
| Standard software features |
Dynamic Disk Pools, SSD read cache, snapshots (up to 128 targets), volume copy, thin provisioning (DDP only), encryption (requires optional FIPS drives), and data assurance. |
| Optional software features |
Snapshots (up to 512 targets), asynchronous mirroring. |
Q1
When can I get the quotation?
We usually quote within 24 hours after receiving your inquiry. If you are in a hurry, please let us know. We will give priority to your inquiry.
Q2
Why choose us?
The best quality and reputation are always our main concerns.
- Our whole machine product provides a 3-year replacement warranty. We have a complete supply chain to deal with after-sales problems.
- All the memories are original brand chips, and we strictly test the memory before each delivery.
- We passed SGS annual audit and financial inspection.
- We accept multiple payment methods to eliminate your concerns.
Q3
What is the minimum order quantity for an OEM order?
Different products have different MOQ. Let us know your requirements and we will try our best to meet your needs. Small orders are also popular.
Q4
Your price is almost our local market price. How can I buy from you at this price?
We have been specialized in this line for many years. We pay attention to quality and believe that only good quality can support long-term business. From the appearance, there is no difference between them, but they have a price gap because they have internal differences, and the same price has different price levels.
Q5
What RAID levels does the DE2000H system support?
The system supports RAID levels 0, 1, 3, 5, 6, and 10, as well as Dynamic Disk Pools. Note that RAID 3 can be configured only through the CLI.
Q6
What is the maximum storage capacity of this system?
With all SFF drives, the system supports up to 1.47 PB (96x 15.36 TB SFF SSDs). With all LFF drives, it supports up to 864 TB (48x 18TB LFF HDDs).
