Nexus AI Server
1 / 4
Enterprise-grade hybrid storage solutions designed to provide performance, capacity, and reliability for modern data centers. Supporting a mix of HDD and SSD drives to balance cost and speed.
| Form Factor | DE2000H 2U24 SFF / 2U12 LFF controller enclosures (2U rack mount). Supports DE240S (2U24 SFF) and DE120S (2U12 LFF) expansion enclosures. |
| Controller Configuration | Dual active-active controller configuration with automatic load balancing. |
| RAID Levels | RAID 0, 1, 3, 5, 6, and 10; Dynamic Disk Pools. (RAID 3 via CLI). |
| System Memory | 16 GB per system (8 GB per controller). Cache mirroring and Flash-backed cache protection. |
| Expansion Support | Up to 3 expansion enclosures (DE120S or DE240S) may be mixed. |
| Drive Bays | Up to 96 SFF hot-swap bays or 48 LFF hot-swap bays per system (1 Controller + 3 Expansion units). |
| Drives Supported | SFF: 10K rpm SAS HDDs, SAS SSDs (1/3 DWD). LFF: 7.2K rpm NL SAS HDDs, SAS SSDs (3 DWD). FIPS encryption options available. |
| Storage Capacity | Up to 1.47 PB with SFF SSDs; Up to 864 TB with LFF HDDs. |
| Host OS Support | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere. |
| Software Features | Dynamic Disk Pools, SSD read cache, snapshots (128-512 targets), volume copy, thin provisioning, asynchronous mirroring. |
